| Profile | 1 | Length | Normally not more than 60m |
| 2 | Width | ≤13000mm | |
| 3 | Height | Eave height of single storey less than 4500mm, two storey less than 7000mm | |
| 4 | Roof Type | Gable roof, slope 1:5; flat roof, slope 1:20 | |
| 5 | Storey | 1-2 storey | |
| Parameter | 6 | Roof Dead Load | 0.3KN/㎡ |
| 7 | Floor Deal Load | 0.5KN/㎡(standard), can be customized | |
| 8 | Floor Live Load | 2.0KN/㎡ | |
| 9 | Roof Live Load (Snow Load) | 0.5KN/㎡ | |
| 10 | Wind Load | 0.45KN/㎡ | |
| Frame | 11 | Column | C profile steel, as per building span, metal code Q345. |
| 12 | Roof Beam | C profile steel, as per building span, metal code Q345 | |
| 13 | Multi-floor Beam | C profile steel, as per building span, metal code Q345 | |
| 14 | Purlin | C85*40*11*1.8 profile steel, metal code Q235/ C120*60*15*1.5 profile steel, metal code Q345 *can be customized as per building layout | |
| 15 | Anti-corrosion Treatment | All frame adopts hot dip galvanization, mass of Zn coating 80g/m²;the joint plate adopt anti-corrosion painting. The treatment of galvanization and painting can be decided as per climate condition and customers' requirement. | |
| Roof | 16 | Material | 50mm - 150mm sandwich panel. The metal sheet can be 0.35-0.5mm in thickness |
| 17 | Color steel metal sheet can be used as per the building function. The metal sheet should be not less than 0.5mm in thickness. | ||
| 18 | Glass wool, the density is not less than 50Kg/m³, Fire-proof in Class A. | ||
| Wall | 19 | Material | 50mm - 150mm sandwich panel. The metal sheet can be 0.35-0.5mm in thickness |
| 20 | Color steel metal sheet can be used as per the building function. The metal sheet should be not less than 0.5mm in thickness. | ||
| 21 | Glass wool, the density is not less than 50Kg/m³, Fire-proof in Class A. | ||
| Door | 22 | Size | 840*2035 |
| 23 | Material | Metal door | |
| Window | 24 | Size | 1125*1490/500*500 |
| 25 | Type | Sliding window, top swing window | |
| 26 | Frame | Standard:PVC | |
| 27 | Glass | Standard: single glazed 4mm glassOption: double glazed 5mm glass | |
| Ceiling | 28 | Material | Standard: Water-proof gypsum boardOption: silicate calcium tile, mineral wool board, aluminum buckle plate, PVC tile *decided by room condition and local climate conditions |
| Floor | 29 | Suspended Flooring System(500mm high in standard) | Integrated bathroom should be used for toilet. Dry room uses laminated wood flooring plate or PVC flooring sheet |
| 30 | Common Floor | (Single storey)wet room uses anti-slipping tiles and dry room uses common ceramic tiles | |
| Multi-flooring | 31 | Dry Room | Laminated wood flooring plate |
| 32 | Wet Room | Integrated bathroom | |
| Electrics | 33 | Capable to provide engineering, layout and construction services | |
| 34 | Lamp | LED 8W/13W/16W for selection *as per room area and room functions | |
| 35 | Socket | Three-pole multi-functional socket(250V 16A) | |
| 36 | Electric Wires | For lamp BV-1.5mm² /common socket BV-2.5mm² /AC and water heater socket BV-4mm² | |
| 37 | Voltage | 220/380V | |
| 38 | Breakers | high breaking circuit breaker/leakage protection circuit breaker *as per functions | |
| Plumping | 39 | Capable to provide engineering, layout and construction services | |
| 40 | Water Supply | PPR | |
| 41 | Water Drainage | UPVC | |
